Freedom Won LiTE Business 40/32 HV Lithium Battery

The Freedom Won LiTE Business 40/32 HV is a high capacity 40kWh energy storage solution, engineered for commercial and industrial applications requiring reliable, long-lasting, and efficient power management. Utilizing advanced lithium-ion technology, this battery ensures optimal performance for backup power systems, renewable energy storage, and peak load management.

Designed for high-voltage (HV) applications, the LiTE Business 40/32 HV seamlessly integrates with compatible inverters, providing superior efficiency and scalable energy storage. Multiple units can be connected in parallel to meet expanding power demands.

Key Features & Benefits

• 40kWh High-Capacity Storage – Ideal for commercial, industrial, and large-scale residential energy needs.
• Scalable & Modular Design – Supports parallel connections to expand capacity as required.
• Long Lifecycle & Reliability – Delivers up to 8000 cycles at 80% Depth of Discharge (DoD), ensuring over 15 years of operation.
• Optimized for High-Voltage Systems – Enhances efficiency and reduces energy losses.
• Advanced Battery Management System (BMS) – Ensures optimal cell performance, safety, and longevity.
• Seamless Inverter Compatibility – Works with leading HV inverter brands for easy system integration.
• Eco-Friendly & Maintenance-Free – Built with Lithium Iron Phosphate (LiFePO₄) technology, offering a safe, non-toxic, and low-maintenance energy solution.

Dimensions & Build

• Size (H x W x D) [mm] – 1260x740x290
• Enclosure – Aluminium, powder-coated white front, rated for indoor installation
• DC Connection – Integrated cables (1 x 70mm² per electrode)

Control Interface & Connectivity

• RJ45 Socket x 2 – CAN Bus for interfacing with compatible inverters and system controllers
• Communication for parallel battery connection – (All batteries must be of the same model)

Protection & Safety Features

• Shunt Trip Circuit Breaker – Triggers on critical faults, manual reset required
• Built-in Protections – Overcurrent, cell under/over voltage, temperature control, weak cell detection, and minimum SOC management

Human Interface & Monitoring

• State of Charge Display – 0 to 100%
• Error Light & Reset Button
• USB Plug – For programming
• Wi-Fi Remote Monitoring – Available as an optional accessory

Warranty & Service Life

• Warranty – 10 years or 4,000 cycles at 80% DoD (maximum 90% DoD)
• Expected Service Life:
  • >16 years (5,500+ cycles) at 80% DoD
  • >20 years (7,500+ cycles) at 50% DoD

Essential Accessories

• USB “printer” cable – Required for battery-to-PC connection (included)
• CAN Bus Termination Resistor – One required per battery (included)
• CAN Bus Cable (RJ45 LAN Cable) – Required per battery (not included)
